Free Flow Portable Air Cooler
Portable Cooler on Wheels
The portable air cooler is a free-flow ductless air cooler ideal for industrial and commercial uses and spot cooling. This model comes with an Axial Fan for better air spread. Multiple coolers can be installed to cover larger areas. Its Plug and Play and easy to move around.
Features
Metal body portable air coolers
Large size air cooler on wheels
Heavy-duty lockable caster wheels
Multiple speed axial fan for high and better air spread
Low noise
EcoCool evaporative cooling pads Inside
Pre-coated galvanized steel
Axial Fan
Benefits
Easy movement, move anywhere you like
Better air management
Easy to Install - Plug and play
Long, trouble-free life compared to cheap imported plastic body coolers
Trusted brand & innovative technology
Ideal for
Industrial & commercial applications with space constraints for ductable coolers. Multiple coolers can be placed for adequate cooling in larger areas.
Commercial Complexes
Restaurant
Company Canteens
Shopping Malls
Banquets
Marriage Halls
Poultry
Green House & Nursery
Textile Mills
Plastic Printing & Packaging Industry
General Manufacturing facilities
Tea Factories
Ideal for
Industrial & commercial applications with space constraints for ductable coolers. Multiple coolers can be placed for adequate cooling in larger areas.
Commercial Facilities
- Commercial Complexes.
- Restaurant, Company canteens
- Shopping Malls, Banquets, Marriage Halls
- Residential Buildings
- Poultry
- Green House & Nursery
- And many more
Industrial Facilities
- Textile Mills
- Automotive Industry
- Plastic Printing & Packaging Industry
- General Manufacturing facilities
- Tea Factories
- Workshops & Warehouses
Range of Products
 |
||
| Model | APC | |
| Body Material | Special Pre-plasticsized coated galvanished steel | |
| Minimum Evaporation Efficiency (%) | 80 | |
| Pad Surface Area (m2) | 1.14 | |
| Pad Thickness (mm) | 100 | |
| Connection Load (kw) | 0.61 | |
| Power Supply | 230/1Ph/50Hz | |
| Overall Dimensions (L x W x H) (mm) | 750x1150x1550 | |
| All Discharge Grill Size (mm) | Free | |
| Fan Type | Axial | |
| Tank Capacity (Liter) | 120 | |
| Dry Weight* (Kgs) | 80 | |
| * Industrial long life construction (heavy duty) | ||
| Design Guide- SI Units | |
| Model | APC |
| Air Flow CMH | 18000 |
| Cooling Space/Area Sq.Ft. | 2000 |
| Throw meter | 25 |
|
Free Flow With Axial Fan APC-20K |
||
| Description | UOM | APC-20K |
| Air Flow at given ESP | m3/h | 18000 |
| Minimum Evaporation Efficiency | % | 80 |
| Pad Surface Area | m2 | 1.14 |
| Pad Thickness | mm | 100 |
| Connection Load | kw | 0.61 |
| Power Supply | 230/1Ph/50Hz | |
| Overall Dimensions (L x W x H) | mm | 750x1150x1550 |
| Connection Size | mm | Free |
| Tank Capacity | Liter | 120 |
| Dry Weight | Kgs | 80 |
|
|
|
| Model | APC |
| Body Material | Special Pre-plasticsized coated galvanished steel |
| Minimum Evaporation Efficiency (%) | 80 |
| Pad Surface Area (m2) | 1.14 |
| Pad Thickness (mm) | 100 |
| Connection Load (kw) | 0.61 |
| Power Supply | 230/1Ph/50Hz |
| Overall Dimensions (L x W x H) (mm) | 750x1150x1550 |
| All Discharge Grill Size (mm) | Free |
| Fan Type | Axial |
| Tank Capacity (Liter) | 120 |
| Dry Weight* (Kgs) | 80 |
| * Industrial long life construction (heavy duty) | |
| Design Guide- SI Units | |||||
| Model | Air Flow CMH | Cooling Space/Area Sq.Ft. | Throw meter | ||
| APC | 18000 | 2000 | 25 | ||
